Glory1604

Single-pass Corrugated Digital Inkjet Press

Single Pass technology brings revolutionary productivity and image quality

Printing speed is up to 150m/min, and printing resolution is up to 600*1200dpi

Can be upgraded to 6-color printing with “C/M/Y/K +2 colors” according to customer needs

· Advantage · Parameters

Dimensions(LWH)	Glory1604:12.85.72.3 m Glory1604+Dryer:21.95.72.6 m Glory1604+Dryer+Varnish:23.95.72.6 m
Productivity	Linear speed up to 150m/min
Substrate/Handling(W*L)	Types:Wide range of corrugated boards(coated,white,kraft etc.) Max. board size:16002800mm Mini. board size:450400mm Thickness:1.5-11mm Handing:Lead-edge feeder, precise media positioning, vacuum suction, conveyor belt; All designed for reliable and high-quality printing.
Printing	Technology:Single-pass, drop-on-demand,piezo inkjet technology. Print head:Industrial inkjet print heads with piezo technology（max.14 pcs per color） Width:Max. printing width 1510mm Ink type:Han FullColor®aqueous ink Ink color:Cyan, Magenta, Yellow, Black(CMYK) Drying:Infrared drying system
Printing modes
Resolution	600x400	600x600	600x900	600x1200
Linear Speed	150m/min	100m/min	66m/min	50m/min
RIP	Software:3rd party RIP Software Input formats:PDF,EPS,TIFF,JPEG, and AI etc Provide color solutions for various printing substrates
Features	Warp detecting and warning system Automatic ink cost calculating function Remote defect diagnosis & system upgrades Production management system available
Operating environment	Temperature:22°-30°C Humidity:40%-80%RH (non-condensing ) Power supply:AC380V 3P+PE 50/60Hz Air supply:6 bar(85Psi)to 8.4 bar (120Psi)
Total Power	Glory1604（Primer optional included）:158Kw (Dryer 75 kw included)\|In Actual Production (Reference Only):64KW Glory1604（brush roller optional included）:141Kw (Dryer 60kw included)\|In Actual Production (Reference Only):64KW Tunnel Dryer:193 Kw (Dryer 144kw included)\|In Actual Production (Reference Only):131KW varnishing Unit:77Kw (Dryer 60kw included)\|In Actual Production (Reference Only):62KW
Weight	Glory1604（Primer optional included）:17.5T Glory1604 (brush roller optional included):16.6T Tunnel Dryer:11.6T Varnishing Unit:3.8T
© The above information is for reference only. Shenzhen Hanway Industrial Digital Equipment Co., Ltd. reserves the right for final interpretation. If any modification happens, no notification will be made and the provisions of the contract shall prevail.
