Model |
HighJet2500B |
|
Applications |
Kraft, Coated, Personalized Applications such as Display Shelf, UV Solutions ( PVC Expansion Sheet/Acrylic) etc. |
|
Ink Type |
Han FullColor Water-Based Ink |
|
Print head |
Industrial inkjet print heads with piezo technology |
|
Dryer |
IR & Hot air |
|
Ink Supply |
Automatic |
|
Print head Configuration |
Standard: 8 printheads, double-row 4 colors (CMYK), maximum 8 printheads |
| Capacity | 1pass：600㎡/hr
2pass：300㎡/hr |
|
Media | Max. Width:2500mm
Automatic loading length：2500mm
Manual loading length：4000mm
Manual loading length：1.5-15mm |
|
Loading & Receiving System | Loading：Auto,Receiving：Automatic |
|
Software |
3rd party RIP Software |
|
Input format |
PDF, JPEG, TIFF、AI、CDR etc. |
|
Site requirement (Min) |
6910 mm (W)*8730 mm (L)*2500 mm (H) |
|
Power |
3Phase/380V, 100A, 50HZ, Total Power 50KW |
|
Air Supply |
Pressure: ≥ 6Kg/cm² ; Speed ≥ 34 liters/min |
|
Environment |
Relative humidity:40%-60%; Temperature: 15℃ -28℃ |
|
Measurement |
4910 mm (W) x 5730 mm (L) x 1965 mm (H) (Take feeding direction as length) |
|
Weight |
7500 Kg (Feeding section included) |
| © The above information is for reference only. Shenzhen Hanway Industrial Digital Equipment Co., Ltd. reserves the right for final interpretation. If any modification happens, no notification will be made and the provisions of the contract shall prevail. |
