Dye Sublimation Printers
Empower Textile Competitiveness
  • Direct to Fabric Printer
  • Dye Sublimation Printer
  • Single Pass Printer
  • HM1800R pro

    High Speed Roll-to-roll Dye-sublimation Printer

    Maximum productivity: 445m/hr

    Maximum resolution: 600*1200dpi

    Print head : 4-8 pcs (Kyocera printhead, single & dual channel optional)

    Model HM1800R pro
    Print head 4-8 pcs (Kyocera printhead, single & dual channel optional)
    Print mode

    Pass1pass2pass
    Printing Mode 600*600dpi 600*1200dpi
    Production Speed330m/hr 165m/hr
    Material  information Maximum Substrate width:1800mm
    Maximum printing width:1900mm
    Material Weight:Minimum 31g/m2

    Media Conveying Roll to roll
    Printer3945mm * 1000mm * 1718mm(L*W*H)
    Ink Color4、6、8 colors optional
    Ink tank volume40L(4 colors)、15L(8 colors)
    Media TypeDye Sublimation paper
    Max Roll Diameter1meter
    Dryer typeConstant temperature hot air drying

    Compressed air supply 0.6 Mpa|1m³/hr(dry without  oil or water vapor)
    Power supply AC380V±10% ,three phase| 11.5A ( 6KW) |50Hz/60Hz
    Working EnvironmentTemperature :20~28℃ degrees Celsius(68~77℉ degrees Fahrenheit),Relative humidity:45﹪-60﹪ (no condensation)


    Software Module
    Constant-Temperature Drying
    Paper Flattening
