HM1800R pro
High Speed Roll-to-roll Dye-sublimation Printer
Maximum productivity: 445m/hr
Maximum resolution: 600*1200dpi
Print head : 4-8 pcs (Kyocera printhead, single & dual channel optional)
|
Model |
HM1800R pro |
|
|
|
Print head |
4-8 pcs (Kyocera printhead, single & dual channel optional) |
|
|
|
Print mode |
|
|
|
|
Pass | 1pass | 1pass | 2pass |
|
Printing Mode |
600*600dpi | 400*600dpi |
600*1200dpi |
|
Production Speed | 330m/hr | 445m/hr |
165m/hr |
|
Material information |
Maximum Substrate width：1800mm
Maximum printing width：1900mm
Material Weight：Minimum 31g/m2 |
|
|
|
Media Conveying |
Roll to roll |
|
|
|
Printer | 3945mm * 1000mm * 1718mm（L*W*H） |
|
|
|
Ink Color | 4、6、8 colors optional |
|
|
|
Ink tank volume | 40L(4 colors)、15L(8 colors) |
|
|
|
Media Type | Dye Sublimation paper |
|
|
|
Max Roll Diameter | 1meter |
|
|
|
Dryer type | Constant temperature hot air drying
|
|
|
|
Compressed air supply |
0.6 Mpa｜1m³/hr（dry without oil or water vapor） |
|
|
|
Power supply |
AC380V±10% ，three phase｜ 11.5A ( 6KW) |50Hz/60Hz |
|
|
|
Working Environment | Temperature ：20~28℃ degrees Celsius（68~77℉ degrees Fahrenheit）,Relative humidity：45﹪－60﹪ （no condensation） |
|
|
